E2E-X5E1
RoHS
RoHS compliant
RoHS compliantPackage Cylinder, Threaded - M18
Category Sensors, Transducers / Proximity Sensors
Description
OMRON INDUSTRIAL AUTOMATION E2EX5E1 PROXIMITY SWITCH, M18, NPN
PDF
/
Buying Options
Total Price: USD $77.35
Unit Price: USD $77.346878
≥1 USD $77.346878
Inventory: 9395
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Brackets, DIN Rail, Panel
Package / Case Cylinder, Threaded - M18
Number of Pins 4
Housing Material Brass
Material - Body Nickel-Plated Brass
Technical
Operating Temperature -40°C~85°C
Published 1999
Series E2E
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Cable Leads
Voltage - Supply 10V~40V
Shielding Shielded
Ingress Protection IP67
Termination Style Cable Leads
Output Voltage 2V
Output Type NPN-NO, 3-Wire
Max Output Current 200mA
Operating Supply Voltage 24V
Response Time 5 ms
Thread Size M18
Sensing Distance 0.197 (5mm)
Sensor Type Inductive
Indicator LED
Load Current 200mA
Max Supply Voltage (DC) 40V
Min Supply Voltage (DC) 10V
Switching Frequency 600Hz
Output Range 200mA
Measurement Range-Max 5 mm
Measurement Range-Min 5 mm
Dimensions
Length 42.9mm
Body Height 18mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Contains Lead
