8010
RoHS
/
Package Epoxy
Category Prototyping, Fabrication Products / Prototype Boards Perforated
Description
VECTOR ELECTRONICS 8010PCB, Pad/Hole 2 sides
PDF
/
Buying Options
Total Price: USD $4.4
Unit Price: USD $4.4
≥1 USD $4.4
≥10 USD $4.06824
≥100 USD $3.628152
≥500 USD $3.18839
Inventory: 183
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Board Thickness 0.062 1.57mm 1/16
Thickness 1.57mm
Height 1.57mm
Technical
Oven Supply Voltage 3.3V
Frequency Stability-Voltage 0.01 ppm
Warm-up Time-Max 5Minute
Input Power 1.32W
Circuit Pattern Pad Per Hole (Round)
Warm-up Power 3.135W
Proto Board Type Breadboard, General Purpose
Aging 0.1 PPM/YEAR
Hole Diameter 0.042 (1.07mm)
Frequency Adjustment-Mechanical NO
Evaluation Kit Yes
Output Load 15 pF
Oscillator Type LVCMOS
Plating Plated Through Hole (PTH)
Supply Voltage-Min (Vsup) 3.135V
Supply Voltage-Max (Vsup) 3.465V
Operating Frequency 10MHz
Operating Temperature (Min) -40°C
Physical Dimension 25.4mm x 22.0mm x 12.1mm
Operating Temperature (Max) 85°C
Frequency Stability 0.01%
Reach Compliance Code compliant
Supply Voltage 3.3V
Pitch 0.100 2.54mm
Additional Feature TAPE AND REEL
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 13.00Lx4.00W 330.2mmx101.6mm
Series Vectorbord? Circbord?
Physical
Package / Case Epoxy
Mount PCB
Contact Material Glass
Supply Chain
Factory Lead Time 2 Weeks
