DSC8104BI2
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description
Programmable Oscillators Unprog MEMS Oscillator, -40C-85C, 25ppm
PDF
/
Buying Options
Total Price: USD $3.75
Unit Price: USD $3.7488
≥1 USD $3.7488
≥10 USD $3.1152
≥100 USD $2.8424
Inventory: 292
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Height 889μm
Technical
Max Duty Cycle 52 %
Max Supply Current 42mA
Load Capacitance 2pF
Available Frequency Range 10MHz~460MHz
Programmable Type Blank (User Must Program)
Physical Dimension 5.0mm x 3.2mm x 0.85mm
Base Resonator MEMS
Function Standby
Output HCSL
Frequency Stability 25 ppm
Frequency 460MHz
Voltage - Supply 2.25V~3.6V
Type XO (Standard)
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series DSC8104
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 4
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
