DSC8103BI2T
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description
Programmable Oscillators Unprog MEMS Oscillator, -40C-85C, 25ppm
PDF
/
Inventory: 7934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Height 889μm
Technical
Max Duty Cycle 52 %
Max Supply Current 32mA
Load Capacitance 2pF
Available Frequency Range 10MHz~460MHz
Programmable Type Blank (User Must Program)
Current - Supply (Disable) (Max) 95μA
Symmetry-Max 52/48%
Fall Time-Max 0.2ns
Rise Time-Max 0.2ns
Physical Dimension 5.0mm x 3.2mm x 0.85mm
Base Resonator MEMS
Function Standby
Output LVDS
Frequency Stability ±25ppm
Frequency 460MHz
Voltage - Supply 2.25V~3.6V
Type XO (Standard)
Termination Solder
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series DSC8103
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 4 Weeks
