DSC8103AI2T
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead Exposed Pad
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description
MEMS OSC PROG BLANK 10MHZ-460MHZ
PDF
/
Inventory: 2156
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead Exposed Pad
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2013
Series DSC8103
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type XO (Standard)
Voltage - Supply 2.25V~3.6V
Frequency Stability ±25ppm
Output LVDS
Function Standby
Base Resonator MEMS
Physical Dimension 7.0mm x 5.0mm x 0.85mm
Rise Time-Max 0.2ns
Fall Time-Max 0.2ns
Symmetry-Max 52/48%
Current - Supply (Disable) (Max) 95μA
Programmable Type Blank (User Must Program)
Available Frequency Range 10MHz~460MHz
Max Supply Current 32mA
Frequency Adjustment-Mechanical NO
Operating Frequency-Max 460MHz
Operating Frequency-Min 10MHz
Dimensions
Height 889μm
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status ROHS3 Compliant
