DSC8102AI2T
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description
Programmable Oscillators Unprog MEMS Oscillator, -40C-85C, 25ppm
PDF
/
Inventory: 8089
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series DSC8102
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Solder
Type XO (Standard)
Voltage - Supply 2.25V~3.6V
Frequency 460MHz
Frequency Stability ±25ppm
Output LVPECL
Function Standby
Base Resonator MEMS
Physical Dimension 7.0mm x 5.0mm x 0.85mm
Operating Frequency 10MHz
Operating Supply Voltage 3.3V
Rise Time-Max 0.25ns
Fall Time-Max 0.25ns
Symmetry-Max 52/48%
Current - Supply (Disable) (Max) 95μA
Programmable Type Blank (User Must Program)
Available Frequency Range 10MHz~460MHz
Max Supply Current 58mA
Max Duty Cycle 52 %
Dimensions
Height 889μm
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q100
