DSC8101CI1
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description
Programmable Oscillators Unprog MEMS Oscillator, -40C-85C, 50ppm
PDF
/
Inventory: 3821
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Number of Pins 6
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series DSC8101
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type XO (Standard)
Voltage - Supply 2.25V~3.6V
Frequency 170MHz
Frequency Stability 50 ppm
Output CMOS
Function Standby
Base Resonator MEMS
Physical Dimension 3.2mm x 2.5mm x 0.85mm
Operating Supply Voltage 3.3V
Rise Time-Max 2ns
Fall Time-Max 2ns
Symmetry-Max 55/45%
Programmable Type Blank (User Must Program)
Available Frequency Range 10MHz~170MHz
Load Capacitance 15pF
Max Supply Current 35mA
Max Duty Cycle 55 %
Dimensions
Height 889μm
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status ROHS3 Compliant
