DSC8004CI2
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description
Programmable Oscillators Unprog MEMS Oscillator, -40C-85C, 25ppm
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
Inventory: 575
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Height 889μm
Technical
Max Supply Current 16.6mA
Load Capacitance 40pF
Available Frequency Range 1MHz~150MHz
Programmable Type Blank (User Must Program)
Current - Supply (Disable) (Max) 15μA
Fall Time-Max 3ns
Rise Time-Max 3ns
Operating Supply Voltage 3.3V
Physical Dimension 3.2mm x 2.5mm x 0.85mm
Base Resonator MEMS
Function Standby
Output CMOS
Frequency Stability 25 ppm
Frequency 150MHz
Supply Voltage 3.3V
Voltage - Supply 1.8V~3.3V
Type XO (Standard)
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series DSC8004
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 4
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
Alternative Model
