DSC8003CI2
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description
ROHS3Compliant Standby Blank (User Must Program) MEMS Programmable Oscillator 55/45% 3ns -40C~85C 3.3V
PDF
/
Inventory: 9027
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Technical
Operating Frequency-Min 1MHz
Operating Frequency-Max 150MHz
Frequency Adjustment-Mechanical NO
Available Frequency Range 1MHz~150MHz
Programmable Type Blank (User Must Program)
Symmetry-Max 55/45%
Fall Time-Max 3ns
Rise Time-Max 3ns
Physical Dimension 3.2mm x 2.5mm x 0.85mm
Current - Supply (Max) 15mA
Base Resonator MEMS
Function Standby
Output CMOS
Frequency Stability ±25ppm
Supply Voltage 3.3V
Voltage - Supply 1.8V~3.3V
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series DSC8003
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
