DSC8002BI1 image
Favorite
DSC8002BI1 image
Favorite
RoHS
RoHS RoHS compliant
Package 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description Programmable Oscillators Unprog MEMS Oscillator, -40C-85C, 50ppm
PDF
/
Inventory: 1629
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 3.2004mm
Length 5.0038mm
Height Seated (Max) 0.035 0.90mm
Height 889μm

Technical

Max Duty Cycle 55 %
Max Supply Current 10mA
Load Capacitance 15pF
Min Supply Voltage 1.65V
Max Supply Voltage 3.6V
Available Frequency Range 1MHz~150MHz
Programmable Type Blank (User Must Program)
Current - Supply (Disable) (Max) 1μA
Current - Supply (Max) 10mA
Base Resonator MEMS
Function Standby
Output CMOS
Frequency Stability ±50ppm
Frequency 150MHz
Voltage - Supply 1.8V~3.3V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type XO (Standard)
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series DSC8002
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Number of Pins 4
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
