ECS-UPO-8PIN
RoHS
/
Package 8-DIP, 4 Leads (Half Size, Metal Can)
Category Crystals, Oscillators, Resonators / Programmable Oscillators
Description
OSC BLANK UNPROGRAMMED HALF SIZE
PDF
/
Inventory: 5113
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Current - Supply (Max) 45mA
Programmable Type Blank (User Must Program)
Available Frequency Range 1MHz~150MHz
Base Resonator Crystal
Function Enable/Disable
Output CMOS
Frequency Stability ±50ppm ±100ppm
Voltage - Supply 3.3V 5V
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.520Lx0.520W 13.20mmx13.20mm
Published 2002
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height Seated (Max) 0.213 5.40mm
Compliance
RoHS Status Non-RoHS Compliant
Physical
Package / Case 8-DIP, 4 Leads (Half Size, Metal Can)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 12 Weeks
