VPS12-6300-B

Triad Magnetics
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 80VA CHAS MOUNT
PDF
/
Inventory: 945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Chassis Mount
Mounting Type Chassis Mount
Weight 2.8lbs 1.3kg

Technical

Published 2014
Series Chassis Mount: World Series?
Size / Dimension 63.50mm Lx58.67mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Type Laminated Core
Max Power Dissipation 80W
Termination Style Solder, Quick Connect
Voltage - Isolation 4000Vrms
Max Output Current 6.3A
Current - Output (Max) Parallel 12.6A Series 6.3A
Power - Max 80VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V

Dimensions

Height Seated (Max) 76.20mm

Compliance

RoHS Status ROHS3 Compliant
