VPP28-360

Triad Magnetics
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 10VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $7.25
Unit Price: USD $7.2512
≥1 USD $7.2512
≥10 USD $5.55544
≥100 USD $5.434176
Inventory: 1099
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 39.67mm
Length 47.63mm
Height Seated (Max) 34.93mm
Height 34.925mm

Technical

Secondary Winding(s) Dual
Voltage - Secondary (Full Load) Parallel 14V Series 28V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Nominal Input Voltage 115V
Power - Max 10VA
Output Current 720mA
Element Configuration Dual
Current - Output (Max) Parallel 720mA Series 360mA
Max Output Current 360mA
Output Voltage 28V
Voltage - Isolation 4000Vrms
Approval Agency CSA, UL, VDE
Termination Style PC Pin
Current Rating 720mA
Max Power Dissipation 10W
Power Rating 10W
Type Laminated Core
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 47.63mm Lx39.67mm W
Series PC Mount: World Series?
Published 2007
Packaging Bulk

Physical

Weight 0.53lb 240.4g
Number of Pins 8
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 17 Weeks
