VPP28-2000

Triad Magnetics
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 56VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $16.82
Unit Price: USD $16.8168
≥1 USD $16.8168
≥10 USD $14.83768
≥100 USD $14.343296
≥500 USD $13.893088
Inventory: 203
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 46.02mm
Height 46.0248mm

Technical

Voltage - Secondary (Full Load) Parallel 14V Series 28V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Nominal Input Voltage 115V
Power - Max 56VA
Output Current 4A
Current - Output (Max) Parallel 4A Series 2A
Max Output Current 2A
Output Voltage 28V
Voltage - Isolation 4000Vrms
Approval Agency CSA, UL, VDE
Termination Style PC Pin
Current Rating 4A
Max Power Dissipation 56W
Power Rating 56W
Type Laminated Core
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 76.20mm Lx63.50mm W
Series PC Mount: World Series?
Published 2007
Packaging Bulk

Physical

Weight 1.7lbs 771.1g
Number of Pins 8
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 17 Weeks
