FP230-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Transformer;2.5VA;Sec:Ser 0.01A,Par 0.02A;Pri:115/230V;Sec:Ser 230VCT,Par 115V
PDF
/
Buying Options
Total Price: USD $9.06
Unit Price: USD $9.060236
≥1 USD $9.060236
≥10 USD $8.547392
≥100 USD $8.063576
≥500 USD $7.607147
≥1000 USD $7.176553
Inventory: 1096
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Number of Pins 8
Weight 0.313lb 141.97g
Technical
Published 2006
Series Flat Pack?
Size / Dimension 47.63mm Lx39.67mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Laminated Core
Power Rating 2.5W
Termination Style PC Pin
Approval Agency UL
Voltage - Isolation 2000Vrms
Current - Output (Max) Parallel 20mA Series 10mA
Element Configuration Dual
Power - Max 2.5VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 120V Series 230V
Secondary Winding(s) Dual
Dimensions
Height 16.5mm
Height Seated (Max) 16.51mm
Length 47.6mm
Width 39.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
