3FS-420
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $8.73
Unit Price: USD $8.7296
≥1 USD $8.7296
≥10 USD $6.68712
≥100 USD $5.665792
≥500 USD $5.572864
≥1000 USD $5.294168
≥3000 USD $5.238394
Inventory: 260
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 34.55mm
Technical
Secondary Winding(s) Dual
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Power - Max 6VA
Current - Output (Max) Parallel 600mA Series 300mA
Max Output Current 300mA
Voltage - Isolation 2500Vrms
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 6W
Power Rating 6W
HTS Code 8504.31.40.35
Additional Feature PCB MOUNTABLE
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 41.50mm Lx34.83mm W
Series 3FS-4xx
Published 2006
Packaging Bulk
Physical
Weight 200g
Number of Pins 6
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 24 Weeks
