3FS-212
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 1.1VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $4.89
Unit Price: USD $4.8928
≥1 USD $4.8928
≥10 USD $3.71536
≥100 USD $3.617504
≥500 USD $3.12862
≥1000 USD $3.030799
≥3000 USD $2.93304
Inventory: 639
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 25.40mm
Height 25.4mm
Technical
VA Rating 1.1 VA
Secondary Winding(s) Dual
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Power - Max 1.1VA
Current - Output (Max) Parallel 180mA Series 90mA
Max Output Current 90mA
Voltage - Isolation 2500Vrms
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 1.1W
Power Rating 1.1W
HTS Code 8504.31.40.35
Additional Feature PCB MOUNTABLE
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 35.56mm Lx31.00mm W
Series 3FS-2xx
Published 2006
Packaging Bulk
Physical
Weight 77.1g
Number of Pins 6
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
