3FL30-85
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 2.5VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $8.22
Unit Price: USD $8.2192
≥1 USD $8.2192
≥10 USD $6.578
Inventory: 372
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 8
Weight 142g
Technical
Packaging Bulk
Published 2007
Series 3FL
Size / Dimension 47.60mm Lx39.60mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Laminated Core
Power Rating 2.5W
Max Power Dissipation 2.5W
Termination Style PC Pin
Voltage - Isolation 1500Vrms
Max Output Current 85mA
Current - Output (Max) Parallel 170mA Series 85mA
Power - Max 2.5VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 15V Series 30V
Dimensions
Height 16.5mm
Height Seated (Max) 16.80mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
