3FL12-475
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $21.67
Unit Price: USD $21.668102
≥1 USD $21.668102
≥180 USD $8.646759
≥540 USD $8.356609
≥990 USD $8.214815
Inventory: 2345
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Flanges, Through Hole
Mounting Type Through Hole
Number of Pins 8
Weight 198g
Technical
Packaging Bulk
Published 2007
Series 3FL
Size / Dimension 47.60mm Lx39.60mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Laminated Core
Power Rating 6W
Max Power Dissipation 6W
Termination Style PC Pin
Voltage - Isolation 1500Vrms
Max Output Current 475mA
Current - Output (Max) Parallel 950mA Series 475mA
Power - Max 6VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Dimensions
Height 21.6mm
Height Seated (Max) 21.60mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
