3FD-448
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $9.13
Unit Price: USD $9.1256
≥1 USD $9.1256
≥10 USD $6.9916
≥100 USD $5.923104
≥500 USD $5.826128
Inventory: 92
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 8
Weight 200g
Technical
Packaging Bulk
Published 2016
Series 3FD-4xx
Size / Dimension 41.50mm Lx34.83mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Additional Feature PCB MOUNTABLE
Power Rating 6W
Max Power Dissipation 6W
Termination Style PC Pin
Approval Agency UL; CSA
Voltage - Isolation 2500Vrms
Max Output Current 125mA
Current - Output (Max) Parallel 250mA Series 125mA
Power - Max 6VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 24V Series 48V
Number of Secondary Winding 2
VA Rating 6 VA
Dimensions
Height 34.54mm
Height Seated (Max) 38.00mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
