3FD-212

Tamura
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 1.1VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $7.62
Unit Price: USD $7.62401
≥1 USD $7.62401
≥160 USD $3.041989
≥480 USD $2.940896
≥960 USD $2.891006
Inventory: 4151
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Number of Pins 8
Weight 77.1g

Technical

Packaging Bulk
Published 2006
Series 3FD-2xx
Size / Dimension 35.56mm Lx31.00mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Additional Feature PCB MOUNTABLE
Power Rating 1.1W
Max Power Dissipation 1.1W
Termination Style PC Pin
Approval Agency UL; CSA
Voltage - Isolation 2500Vrms
Max Output Current 90mA
Current - Output (Max) Parallel 180mA Series 90mA
Power - Max 1.1VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Number of Secondary Winding 2
VA Rating 1.1 VA

Dimensions

Height 25.4mm
Height Seated (Max) 38.00mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
