3FD-210
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 1.1VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $5.04
Unit Price: USD $5.0424
≥1 USD $5.0424
≥10 USD $3.83328
≥100 USD $3.732608
≥500 USD $3.228174
≥1000 USD $3.127247
≥3000 USD $3.026364
Inventory: 2886
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 8
Weight 77.1g
Technical
Packaging Bulk
Published 2006
Series 3FD-2xx
Size / Dimension 35.56mm Lx31.00mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Additional Feature PCB MOUNTABLE
Power Rating 1.1W
Max Power Dissipation 1.1W
Termination Style PC Pin
Approval Agency UL; CSA
Voltage - Isolation 2500Vrms
Max Output Current 110mA
Current - Output (Max) Parallel 220mA Series 110mA
Power - Max 1.1VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 5V Series 10V
Number of Secondary Winding 2
VA Rating 1.1 VA
Dimensions
Height 25.4mm
Height Seated (Max) 25.40mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
