ST-2-24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 1.1VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $18.6
Unit Price: USD $18.595916
≥1 USD $18.595916
≥200 USD $7.420511
≥500 USD $7.172373
≥1000 USD $7.050273
Inventory: 1157
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.17lb 77.11g
Technical
Series ST
Size / Dimension 34.90mm Lx28.60mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
HTS Code 8504.31.40.35
Max Power Dissipation 1.1W
Frequency 60Hz
Termination Style PC Pin
Approval Agency UL; CSA
Number of Contacts 6
Voltage - Isolation 2500Vrms
Max Output Current 45mA
Current - Output (Max) Parallel 90mA Series 45mA
Output Power 1.1W
Power - Max 1.1VA
Output Voltage 1 12V
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Output Voltage 2 12V
Secondary Winding(s) Dual
VA Rating 1.1 VA
Dimensions
Height 23.8mm
Height Seated (Max) 24.60mm
Length 34.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
