IF-2-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR SEMI-TORO 2VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $16.82
Unit Price: USD $16.8168
≥1 USD $16.8168
≥10 USD $12.8601
≥100 USD $12.365408
Inventory: 732
Minimum: 1
-
+
Technical Details
Technical
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 5V Series 10V
Output Voltage 2 5V
Number of Secondary Winding 2
VA Rating 2 VA
Output Voltage 1 5V
Power - Max 2VA
Current - Output (Max) Parallel 400mA Series 200mA
Max Output Current 200mA
Voltage - Isolation 4000Vrms
Physical Dimension 53mm X 44mm X 17.6mm
Approval Agency UL; CSA; VDE
Termination Style PC Pin
Max Power Dissipation 2W
HTS Code 8504.31.40.35
Additional Feature PCB MOUNTABLE
Type Semi-Toroidal
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 53.00mm Lx44.00mm W
Series IF
Published 2009
Dimensions
Height 17.6mm
Height Seated (Max) 17.60mm
Length 53mm
Width 44mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 4.6lbs 2.1kg
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
