DPC-16-1500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 24VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $16.9
Unit Price: USD $16.896
≥1 USD $16.896
≥10 USD $12.87616
≥100 USD $11.870144
≥500 USD $11.467808
≥1000 USD $11.266552
≥3000 USD $10.864163
Inventory: 114
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 57.2mm
Length 41.3mm
Height Seated (Max) 34.93mm
Height 34.9mm
Technical
VA Rating 24 VA
Number of Secondary Winding 2
Output Voltage 2 8V
Voltage - Secondary (Full Load) Parallel 8V Series 16V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 8V
Power - Max 24VA
Output Power 24W
Current - Output (Max) Parallel 3A Series 1.5A
Max Output Current 1.5A
Voltage - Isolation 1500Vrms
Number of Contacts 8
Approval Agency UL; CSA
Termination Style PC Pin
Frequency 500Hz
Max Power Dissipation 24W
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 41.30mm Lx57.20mm W
Series DPC
Published 2009
Physical
Weight 0.75lb 340.19g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
