DMPC-X-12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 10VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $16.69
Unit Price: USD $16.690096
≥1 USD $16.690096
≥10 USD $15.745368
≥100 USD $14.854122
≥500 USD $14.013328
≥1000 USD $13.220124
Inventory: 9197
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 36.5mm
Length 47.6mm
Height Seated (Max) 41.70mm
Height 41.3mm
Technical
VA Rating 10 VA
Number of Secondary Winding 2
Voltage - Secondary (Full Load) Parallel 5V Series 12V
Center Tap Yes
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Power - Max 10VA
Current - Output (Max) Parallel 360mA Series 60mA
Max Output Current 60mA
Voltage - Isolation 1500Vrms
Physical Dimension 47.6mm X 36.5mm X 41.3mm
Approval Agency UL; CSA
Termination Style PC Pin
Reach Compliance Code unknown
Max Power Dissipation 10W
HTS Code 8504.31.40.35
Additional Feature PCB MOUNTABLE; OTHER SECONDARY IS WITH CENTER TAP
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 47.60mm Lx36.50mm W
Series DMPC
Published 2009
Physical
Weight 0.56lb 254.01g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
