CL2-2.5R-24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 2.5VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $11.52
Unit Price: USD $11.517128
≥1 USD $11.517128
≥10 USD $10.865218
≥100 USD $10.250198
≥500 USD $9.670004
≥1000 USD $9.122634
Inventory: 1086
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.25lb 113.4g
Technical
Series CL2
Size / Dimension 41.30mm Lx36.50mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
Type Laminated Core
Max Power Dissipation 2.5W
Termination Style PC Pin
Voltage - Isolation 4000Vrms
Max Output Current 100mA
Current - Output (Max) 100mA
Power - Max 2.5VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) 24V
Secondary Winding(s) Single
Dimensions
Height Seated (Max) 28.60mm
Length 41.3mm
Width 36.5mm
Compliance
RoHS Status ROHS3 Compliant
