A41-80-512
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 80VA CHAS MOUNT
PDF
/
Buying Options
Total Price: USD $58.68
Unit Price: USD $58.682691
≥1 USD $58.682691
≥200 USD $23.415572
≥500 USD $22.633083
≥1000 USD $22.245778
Inventory: 6359
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 2.8lbs 1.3kg
Technical
Published 2009
Series All-4-One?
Size / Dimension 63.50mm Lx64.30mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Type Laminated Core
Additional Feature OTHER SECONDARY IS WITH CENTER TAP
HTS Code 8504.31.40.65
Max Power Dissipation 80W
Reach Compliance Code unknown
Termination Style Solder, Quick Connect
Approval Agency UL; VDE; CSA
Physical Dimension 63.5mm X 60.3mm X 76.2mm
Voltage - Isolation 4000Vrms
Max Output Current 3.5A
Current - Output (Max) Parallel 3.5A Series 600mA
Output Power 80W
Power - Max 80VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap Yes
Voltage - Secondary (Full Load) Parallel 5V Series 12V
Number of Secondary Winding 2
VA Rating 80 VA
Dimensions
Height 76.2mm
Height Seated (Max) 76.20mm
Length 63.5mm
Width 60.3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
