36-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 144VA CHAS MOUNT
PDF
/
Buying Options
Total Price: USD $73.52
Unit Price: USD $73.5152
≥1 USD $73.5152
≥10 USD $71.06264
≥100 USD $66.161216
≥500 USD $61.260496
Inventory: 36
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 6.8lbs 3.1kg
Technical
Size / Dimension 104.80mm Lx85.70mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Type Laminated Core
Additional Feature THE TWO SECONDARIES HAVE CENTER TAPPED CONNECTIONS
Max Power Dissipation 144W
Reach Compliance Code unknown
Termination Style Solder, Quick Connect
Physical Dimension 104.8mm X 85.7mm X 87.3mm
Voltage - Isolation 1500Vrms
Max Output Current 4A
Current - Output (Max) Parallel 8A Series 4A
Power - Max 144VA
Output Voltage 1 18V
Voltage - Primary 105V 115V 125V
Primary Winding(s) Single, Multiple Taps
Center Tap Yes
Voltage - Secondary (Full Load) Parallel 18V Series 36V
Output Voltage 2 18V
Secondary Winding(s) Dual
Primary Rating SINGLE 115V
Dimensions
Height Seated (Max) 87.30mm
Length 104.8mm
Width 85.7mm
Compliance
RoHS Status ROHS3 Compliant
