241-8-24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 100VA CHAS MOUNT
PDF
/
Buying Options
Total Price: USD $25.28
Unit Price: USD $25.2824
≥1 USD $25.2824
≥10 USD $22.30448
≥100 USD $21.561056
≥500 USD $19.330432
≥1000 USD $18.587008
Inventory: 116
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 57.2mm
Length 102.4mm
Height Seated (Max) 67.70mm
Height 65.1mm
Technical
VA Rating 100 VA
Number of Secondary Winding 1
Voltage - Secondary (Full Load) 24V
Center Tap Yes
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 24V
Power - Max 100VA
Output Power 100W
Max Output Current 4A
Voltage - Isolation 2500Vrms
Physical Dimension 102.4mm X 57.2mm X 65.1mm
Approval Agency UL; CSA
Termination Style Solder, Quick Connect
Frequency 60Hz
Reach Compliance Code unknown
Max Power Dissipation 100W
HTS Code 8504.31.40.65
Type Laminated Core
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 102.40mm Lx58.50mm W
Series Two-4-One?
Published 2009
Physical
Weight 2.8lbs 1.3kg
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 16 Weeks
