241-4-24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA CHAS MOUNT
PDF
/
Buying Options
Total Price: USD $9.94
Unit Price: USD $9.9352
≥1 USD $9.9352
≥10 USD $7.95344
Inventory: 1157
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 0.44lb 199.58g
Technical
Series Two-4-One?
Size / Dimension 60.30mm Lx33.30mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Type Laminated Core
HTS Code 8504.31.40.35
Max Power Dissipation 6W
Reach Compliance Code unknown
Frequency 60Hz
Termination Style Solder, Quick Connect
Approval Agency UL; CSA
Physical Dimension 60.3mm X 31.8mm X 34.9mm
Voltage - Isolation 2500Vrms
Max Output Current 250mA
Output Power 6W
Power - Max 6VA
Output Voltage 1 24V
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap Yes
Voltage - Secondary (Full Load) 24V
Number of Secondary Winding 1
VA Rating 6 VA
Dimensions
Height 34.9mm
Height Seated (Max) 36.20mm
Length 60.3mm
Width 31.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
