241-3-16L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 2.4VA CHAS MOUNT
PDF
/
Buying Options
Total Price: USD $19.04
Unit Price: USD $19.039676
≥1 USD $19.039676
≥225 USD $7.597752
≥525 USD $7.34305
≥975 USD $7.218324
Inventory: 922
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 29.6mm
Length 52.6mm
Height Seated (Max) 31.20mm
Technical
Secondary Winding(s) Single
Voltage - Secondary (Full Load) 16V
Center Tap Yes
Primary Winding(s) Single
Voltage - Primary 115V
Power - Max 2.4VA
Current - Output (Max) 150mA
Max Output Current 150mA
Voltage - Isolation 2500Vrms
Termination Style Wire Leads
Max Power Dissipation 2.4W
Type Laminated Core
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 52.60mm Lx29.60mm W
Series Two-4-One?
Physical
Weight 0.25lb 113.4g
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 16 Weeks
