24-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 96VA CHAS MOUNT
PDF
/
Inventory: 9053
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 79.4mm
Length 95.3mm
Height Seated (Max) 79.40mm
Technical
Primary Rating SINGLE 115V
Secondary Winding(s) Dual
Output Voltage 2 12V
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Center Tap Yes
Primary Winding(s) Single, Multiple Taps
Voltage - Primary 105V 115V 125V
Output Voltage 1 12V
Power - Max 96VA
Current - Output (Max) Parallel 8A Series 4A
Max Output Current 4A
Voltage - Isolation 1500Vrms
Physical Dimension 95.3mm X 79.4mm X 79.4mm
Termination Style Solder, Quick Connect
Reach Compliance Code unknown
Max Power Dissipation 96W
Additional Feature THE TWO SECONDARIES HAVE CENTER TAPPED CONNECTIONS
Type Laminated Core
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 95.30mm Lx79.40mm W
Physical
Weight 4.5lbs 2kg
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 16 Weeks
