ST5-56B35 image
Favorite
ST5-56B35 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 5147
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 39.624mm
Length 47.244mm
Height 36.58mm

Technical

VA Rating 12 VA
Secondary Winding(s) Dual
Output Voltage 2 28V
Voltage - Secondary (Full Load) Parallel 28V Series 56V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 28V
Power - Max 12VA
Current - Output (Max) Parallel 440mA Series 220mA
Max Output Current 220mA
Voltage - Isolation 2500Vrms
Physical Dimension 47.244mm X 39.624mm X 36.576mm
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 12W
Power Rating 12W
HTS Code 8504.31.40.35
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 47.24mm Lx39.62mm W
Series Split Bobbin Plug-In
Published 2009
Packaging Bulk

Physical

Weight 0.7lb 317.51g
Mounting Type Through Hole
Mount Through Hole
