ST5-24B19
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformer 2500Vrms 12VA 6Term. PC Pin Thru-Hole
PDF
/
Inventory: 6847
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 6
Weight 0.7lb 317.51g
Technical
Packaging Bulk
Published 2009
Series Split Bobbin Plug-In
Size / Dimension 47.24mm Lx39.62mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
HTS Code 8504.31.40.35
Power Rating 12W
Max Power Dissipation 12W
Depth 39.6mm
Termination Style PC Pin
Approval Agency UL; CSA
Voltage - Isolation 2500Vrms
Max Output Current 1A
Current - Output (Max) Parallel 1A Series 500mA
Power - Max 12VA
Lead/Base Style PC Pin
Output Voltage 1 12V
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Output Voltage 2 12V
Secondary Winding(s) Dual
VA Rating 12 VA
Dimensions
Height 36.58mm
Length 47.244mm
Compliance
RoHS Status RoHS Compliant
