ST5-20B15
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 9370
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.7lb 317.51g
Technical
Packaging Bulk
Published 2009
Series Split Bobbin Plug-In
Size / Dimension 47.24mm Lx39.62mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Additional Feature PARALLEL CONNECTED; HIGH ISOLATION
Power Rating 12W
Max Power Dissipation 12W
Termination Style PC Pin
Approval Agency UL; CSA
Physical Dimension L47.24XB39.62XH36.58 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 1.2A
Current - Output (Max) Parallel 1.2A Series 600mA
Power - Max 12VA
Output Voltage 1 10V
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Output Voltage 2 10V
Secondary Winding(s) Dual
VA Rating 12 VA
Dimensions
Height 36.58mm
Length 47.24mm
Width 39.62mm
Compliance
RoHS Status RoHS Compliant
