ST2-12B42 image
Favorite
ST2-12B42 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformer 2500Vrms 1.1VA 6Term. PC Pin Thru-Hole
PDF
/
Inventory: 3414
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Seated (Max) 23.86mm
Height 23.88mm

Technical

VA Rating 1.1 VA
Secondary Winding(s) Dual
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Lead/Base Style PC Pin
Power - Max 1.1VA
Current - Output (Max) Parallel 180mA Series 90mA
Max Output Current 90mA
Voltage - Isolation 2500Vrms
Physical Dimension L28.7XB28.7XH23.88 (mm)
Approval Agency UL; CSA
Termination Style PC Pin
Depth 28.7mm
Shielding Unshielded
Max Power Dissipation 1.1W
Power Rating 1.1W
Additional Feature PARALLEL CONNECTED; HIGH ISOLATION
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 28.70mm Lx28.70mm W
Series Split Bobbin Plug-In
Published 2007
Packaging Bulk

Physical

Weight 0.17lb 77.11g
Number of Pins 6
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 14 Weeks
