ST2-120B50
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 1.1VA THRU HOLE
PDF
/
Inventory: 6699
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 28.7mm
Length 28.7mm
Height Seated (Max) 23.86mm
Height 23.88mm
Technical
VA Rating 1.1 VA
Secondary Winding(s) Dual
Output Voltage 2 60V
Voltage - Secondary (Full Load) Parallel 60V Series 120V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 60V
Power - Max 1.1VA
Current - Output (Max) Parallel 20mA Series 10mA
Max Output Current 10mA
Voltage - Isolation 2500Vrms
Physical Dimension L28.7XB28.7XH23.88 (mm)
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 1.1W
Power Rating 1.1W
Additional Feature PARALLEL CONNECTED; HIGH ISOLATION
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 28.70mm Lx28.70mm W
Series Split Bobbin Plug-In
Published 2009
Packaging Bulk
Physical
Weight 0.17lb 77.11g
Mounting Type Through Hole
Mount Through Hole
