PC-56-80B30
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 4.4VA THRU HOLE
PDF
/
Inventory: 1962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 31.75mm
Length 41.27mm
Height Seated (Max) 34.93mm
Height 1.375mm
Technical
VA Rating 4.4 VA
Secondary Winding(s) Dual
Output Voltage 2 28V
Voltage - Secondary (Full Load) Parallel 28V Series 56V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 28V
Power - Max 4.4VA
Current - Output (Max) Parallel 160mA Series 80mA
Max Output Current 80mA
Voltage - Isolation 1500Vrms
Physical Dimension L41.27XB31.75XH34.92 (mm)
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 4.4W
Power Rating 4.4W
HTS Code 8504.31.40.35
Additional Feature PARALLEL CONNECTED
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 41.28mm Lx31.75mm W
Series PC Plug-In
Published 2009
Physical
Weight 0.313lb 141.97g
Mounting Type Through Hole
Mount Through Hole
