PC-230-100B48
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 24VA THRU HOLE
PDF
/
Inventory: 5825
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 57.15mm
Length 41.27mm
Height Seated (Max) 34.93mm
Height 1.375mm
Technical
VA Rating 24 VA
Secondary Winding(s) Dual
Output Voltage 2 115V
Voltage - Secondary (Full Load) Parallel 115V Series 230V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 115V
Power - Max 24VA
Current - Output (Max) Parallel 200mA Series 100mA
Max Output Current 100mA
Voltage - Isolation 1500Vrms
Physical Dimension L41.27XB57.15XH34.92 (mm)
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 24W
Power Rating 24W
HTS Code 8504.31.40.35
Additional Feature PARALLEL CONNECTED
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 41.28mm Lx57.15mm W
Series PC Plug-In
Published 2009
Physical
Weight 0.75lb 340.19g
Mounting Type Through Hole
Mount Through Hole
