LP56-100B15 image
Favorite
LP56-100B15 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformers THT Open-Style PC Mount LowPrfl
PDF
/
Inventory: 7828
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 39.67mm
Length 47.62mm
Height 21.59mm

Technical

VA Rating 6 VA
Number of Secondary Winding 2
Output Voltage 2 28V
Voltage - Secondary (Full Load) Parallel 28V Series 56V
Center Tap No
Primary Winding(s) Dual
Output Voltage 1 28V
Power - Max 6VA
Current - Output (Max) Parallel 200mA Series 100mA
Max Output Current 100mA
Voltage - Isolation 1500Vrms
Physical Dimension L47.62XB39.67XH21.59 (mm)
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 6W
Additional Feature PARALLEL CONNECTED
Type Semi-Toroidal
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 47.63mm Lx39.67mm W
Series Low Profile Plug-In
Published 2007
Packaging Bulk

Physical

Weight 0.438lb 198.67g
Mounting Type Through Hole
Mount Plug-In, Through Hole
