LP24-100B27
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers THT Open-Style PC Mount LowPrfl
PDF
/
Inventory: 6515
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Plug-In, Through Hole
Mounting Type Through Hole
Weight 0.313lb 141.97g
Technical
Published 2007
Series Low Profile Plug-In
Size / Dimension 47.63mm Lx39.67mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Semi-Toroidal
Additional Feature PARALLEL CONNECTED
Max Power Dissipation 2W
Termination Style PC Pin
Approval Agency UL; CSA
Physical Dimension L47.62XB39.67XH16.51 (mm)
Voltage - Isolation 1500Vrms
Max Output Current 100mA
Current - Output (Max) Parallel 200mA Series 100mA
Power - Max 2VA
Output Voltage 1 12V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Output Voltage 2 12V
Number of Secondary Winding 2
VA Rating 2 VA
Dimensions
Height 16.51mm
Length 47.62mm
Width 39.67mm
Compliance
RoHS Status RoHS Compliant
