DST6-56B36
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Inventory: 7926
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.8lb 362.87g
Technical
Packaging Bulk
Published 2009
Series Split Bobbin Plug-In
Size / Dimension 57.15mm Lx47.24mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Additional Feature PARALLEL CONNECTED; HIGH ISOLATION
Power Rating 20W
Max Power Dissipation 20W
Termination Style PC Pin
Approval Agency UL; CSA
Physical Dimension L57.15XB47.24XH36.58 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 350mA
Current - Output (Max) Parallel 700mA Series 350mA
Power - Max 20VA
Output Voltage 1 28V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 28V Series 56V
Output Voltage 2 28V
Number of Secondary Winding 2
VA Rating 20 VA
Dimensions
Height 36.58mm
Length 57.15mm
Width 47.24mm
Compliance
RoHS Status RoHS Compliant
