DST6-12B8 image
Favorite
DST6-12B8 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Inventory: 8297
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 47.244mm
Length 57.15mm
Height 36.58mm

Technical

VA Rating 20 VA
Number of Secondary Winding 2
Output Voltage 2 6.3V
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 6.3V
Power - Max 20VA
Current - Output (Max) Parallel 3.2A Series 1.6A
Max Output Current 1.6A
Voltage - Isolation 2500Vrms
Physical Dimension 57.15mm X 47.244mm X 36.576mm
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 20W
Power Rating 20W
HTS Code 8504.31.40.35
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 57.15mm Lx47.24mm W
Series Split Bobbin Plug-In
Published 2007

Physical

Weight 0.8lb 362.87g
Mounting Type Through Hole
Mount Through Hole
