DST4-120B38
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA THRU HOLE
PDF
/
Inventory: 3524
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.44lb 199.58g
Technical
Packaging Bulk
Published 2009
Series Split Bobbin Plug-In
Size / Dimension 41.40mm Lx33.27mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
HTS Code 8504.31.40.35
Power Rating 6W
Max Power Dissipation 6W
Termination Style PC Pin
Approval Agency UL; CSA
Physical Dimension 41.402mm X 33.274mm X 33.274mm
Voltage - Isolation 2500Vrms
Max Output Current 50mA
Current - Output (Max) Parallel 100mA Series 50mA
Power - Max 6VA
Output Voltage 1 60V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 60V Series 120V
Output Voltage 2 60V
Number of Secondary Winding 2
VA Rating 6 VA
Dimensions
Height 33.27mm
Length 41.402mm
Width 33.274mm
Compliance
RoHS Status RoHS Compliant
