DST2-28B46
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 1.1VA THRU HOLE
PDF
/
Inventory: 1742
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.17lb 77.11g
Technical
Packaging Bulk
Published 2007
Series Split Bobbin Plug-In
Size / Dimension 28.70mm Lx28.70mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
HTS Code 8504.31.40.35
Power Rating 1.1W
Max Power Dissipation 1.1W
Termination Style PC Pin
Approval Agency UL; CSA
Physical Dimension 28.702mm X 28.702mm X 23.876mm
Voltage - Isolation 2500Vrms
Max Output Current 40mA
Current - Output (Max) Parallel 80mA Series 40mA
Power - Max 1.1VA
Output Voltage 1 14V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 14V Series 28V
Output Voltage 2 14V
Number of Secondary Winding 2
VA Rating 1.1 VA
Dimensions
Height 23.88mm
Height Seated (Max) 23.86mm
Length 28.702mm
Width 28.702mm
Compliance
RoHS Status RoHS Compliant
