DPC-230-20B46
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 4.4VA THRU HOLE
PDF
/
Inventory: 5430
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.313lb 141.97g
Technical
Published 2009
Series PC Plug-In
Size / Dimension 41.28mm Lx31.75mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Additional Feature PARALLEL CONNECTED
Power Rating 4.4W
Max Power Dissipation 4.4W
Termination Style PC Pin
Approval Agency UL; CSA
Physical Dimension L41.27XB31.75XH34.92 (mm)
Voltage - Isolation 1500Vrms
Max Output Current 20mA
Current - Output (Max) Parallel 40mA Series 20mA
Power - Max 4.4VA
Output Voltage 1 115V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 115V Series 230V
Output Voltage 2 115V
Number of Secondary Winding 2
VA Rating 4.4 VA
Dimensions
Height 1.375mm
Height Seated (Max) 34.93mm
Length 41.27mm
Width 31.75mm
Compliance
RoHS Status RoHS Compliant
