DPC-120-200B40

Pulse Electronics Power
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 24VA THRU HOLE
PDF
/
Inventory: 4818
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Weight 0.75lb 340.19g

Technical

Published 2009
Series PC Plug-In
Size / Dimension 41.28mm Lx57.15mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Additional Feature PARALLEL CONNECTED
HTS Code 8504.31.40.35
Power Rating 24W
Max Power Dissipation 24W
Termination Style PC Pin
Approval Agency UL; CSA
Physical Dimension L41.27XB57.15XH34.92 (mm)
Voltage - Isolation 1500Vrms
Max Output Current 200mA
Current - Output (Max) Parallel 400mA Series 200mA
Power - Max 24VA
Output Voltage 1 60V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 60V Series 120V
Output Voltage 2 60V
Number of Secondary Winding 2
VA Rating 24 VA

Dimensions

Height 1.375mm
Height Seated (Max) 34.93mm
Length 41.27mm
Width 57.15mm

Compliance

RoHS Status RoHS Compliant
