DPC-12-100B5 image
Favorite
DPC-12-100B5 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformer 1500Vrms 1.2VA 8Term. PC Pin Thru-Hole
PDF
/
Inventory: 8498
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length 34.92mm
Height Seated (Max) 30.18mm
Height 1.188mm

Technical

VA Rating 1.2 VA
Number of Secondary Winding 2
Output Voltage 2 6.3V
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 6.3V
Lead/Base Style PC Pin
Power - Max 1.2VA
Current - Output (Max) Parallel 200mA Series 100mA
Max Output Current 100mA
Voltage - Isolation 1500Vrms
Approval Agency UL; CSA
Termination Style PC Pin
Depth 28.575mm
Max Power Dissipation 1.2W
Power Rating 1.2W
Additional Feature PARALLEL CONNECTED
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 34.93mm Lx28.58mm W
Series PC Plug-In
Published 2009

Physical

Weight 0.188lb 85.28g
Number of Pins 8
Mounting Type Through Hole
Mount Through Hole
