DP241-8-36A57
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 100VA CHAS MOUNT
PDF
/
Inventory: 9117
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 57.15mm
Length 102.36mm
Height Seated (Max) 57.15mm
Technical
VA Rating 100 VA
Secondary Winding(s) Single
Voltage - Secondary (Full Load) 36V
Center Tap Yes
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 36V
Power - Max 100VA
Max Output Current 2.8A
Voltage - Isolation 2500Vrms
Physical Dimension L102.36XB57.15XH65.02 (mm)
Approval Agency UL; CSA
Termination Style Solder, Quick Connect
Max Power Dissipation 100W
Power Rating 100W
Additional Feature HIGH ISOLATION
Type Laminated Core
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 102.36mm Lx65.02mm W
Series Chassis-Tran
Published 2009
Packaging Bulk
Physical
Weight 2.8lbs 1.3kg
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 14 Weeks
